DIST D-2892 CC
Computer-controlled, fully automatic determination of distillation rates, cut points, fraction collection, and weighing.
AUTODEST 800 AC/HV
Special high vacuum model designed to exceed the ASTM standard vacuum range.
The following features apply to both the DIST D-2892 CC and the AUTODEST 800 AC/HV:
- Increase profitability with accurate and complete cut determination of target products thanks to precise control and measurement of pressure, vacuum, temperature, and weight.
- Industry-leading LPG fraction yield with two-stage condensation and jacked first-cut receiver.
- Ensure strict adherence to ASTM D2892.
- Designed with operator safety in mind.
- Only automated system with simultaneous dewatering and debutanization; reducing time and effort while improving the recovery rate of the light ends cut.
| Technical Specifications | |
|---|---|
| Operation Temperature | max. 350 °C in distillation flask |
| Final Cut Temperature | max. 400 – 420 °C AET (depending on product) |
| Operation Pressure | 1 -760 mmHg (Torr) |
| Flask Size | 20 L (stainless steel) |
| Charge | 6.5 – 13 L |
| Separation Efficiency | approx. 15 theoretical plates |
| Fraction Collector | 20 x 1,000 mL (included software extension allows up to 40 receivers) |
| Material | borosilicate glass 3.3, SS 316 L/Ti, PTFE, FPM |
| Power Supply | 230/400 V or 208/480 V, 3P + N + PE, 60 Hz; Others on request |
| Power Consumption | maximum approx. 22.2 kW (single outlet, not including PC or optional calibration stations) |
| Operational Environment | +10 – +30 °C |
| Dimensions (L x D x H) | approx. 2.3 x 0.9 x 3.3 m (incl. circulators, vacuum pump and control cabinet; Options may require an extension of these measurements) |
Industry Applications
These systems are integral to various sectors within the petroleum industry:
Detailed Features Breakdown
The DIST D-2892 CC and AUTODEST 800 AC/HV are equipped with features that enhance their performance and user-friendliness:
Accurately measure temperature, pressure, and vacuum levels, ensuring reliable data collection throughout the distillation process.
Automated collection of distillate fractions with built-in weighing capabilities allows for precise determination of mass and volume, facilitating accurate cut point identification.
Enhances the recovery of light fractions, including LPG, through efficient condensation, improving overall yield and profitability.
Automates the removal of water and light hydrocarbons, streamlining the distillation process and reducing operator intervention.
Accommodates various sample volumes, providing versatility for different operational requirements and research needs.
Benefits of Using the DIST D-2892 CC
The DIST D-2892 CC is the one of the best among distillation solutions. It offers several advantages:
Enhanced operational efficiency
Automation of distillation rates, cut points, and fraction collection reduces manual labor and increases throughput, leading to cost savings and improved productivity.
Accurate data acquisition
Precise control and measurement of distillation parameters ensure high-quality data, supporting informed decision-making in process optimization and product development.
Compliance with industry standards
Strict adherence to ASTM D2892 ensures that distillation processes meet industry benchmarks, facilitating regulatory compliance and market acceptance.
Improved safety measures
Designed with operator safety in mind, these systems include features that minimize exposure to hazardous conditions, ensuring a safer working environment.
By integrating the DIST D-2892 CC or AUTODEST 800 AC/HV into your operations, you can achieve precise and efficient crude oil distillation, supporting both productivity and quality in your processes.
